Garmin Reactor 40 Mechanical/Retrofit/Solenoid Corepack with GHC 50 Autopilot Instrument Pack – 010-02794-02 | OEM

Garmin Reactor 40 Mechanical/Retrofit/Solenoid Corepack with GHC 50 Autopilot Instrument Pack – 010-02794-02

Every captain needs a co-pilot. Built for powerboats, the Garmin Reactor 40 Mechanical/Retrofit/Solenoid Corepack with GHC 50 Autopilot Instrument (010-02794-02) gives you the extra hand you need so you can explore worry-free. It's the perfect match for mechanical, retrofit and solenoid steering systems, and it includes the GHC™ 50 touchscreen display.

Key Features

• Made for mechanical/retrofit/solenoid steered systems
• Choose a class A, class B compact or class B drive unit for your steering system (sold separately); all Garmin linear drives include built-in rudder feedback sensing
• Solid-state 9-axis AHRS, so you can mount it nearly anywhere
• Reacts to sea conditions to keep you on course, even when pitching or rolling
• Fast, easy calibration
• Control your autopilot from anywhere on board with a compatible Garmin chartplotter
• Optional GRF™ 10 sensor available to further enhance your setup

ECU/CCU Specifications

• CCU dimensions: 4.3" x 4.4" x 1.9" (10.9 x 11.2 x 4.8 cm)
• ECU dimensions: 6.6" x 4.6" x 2.1" (16.8 x 11.7 x 5.3 cm)
• Supply voltage: 10 to 30 V
• Operating temperature: -15° C to 60° C (5° F to 140° F)

Buzzer/Alarm Specifications

• Dimensions (L × diameter): 29/32" × 1" (23 mm × 25 mm)
• Weight: 2.4 oz (68 g)
• Temperature range: 5°F to 131°F (-15°C to 55°C)
• Cable length: 10' (3.0 m)

GHC™ 50 Specifications

• Dimensions (H x W x D): 5.5” x 4.1” x 2.0” (14.0 x 10.5 x 5.1 cm)
• Display type: 800 x 480 WVGA
• Display size: 5" (12.7 cm)
• Touch display: yes
• Knob control: with GRID 10/20
• Remote control via ANT+® connectivity: yes
• Wi-Fi connectivity: yes
• NMEA 2000 networking: yes
• Ethernet: yes

What's In The Box

• Reactor 40 CCU (Course Computer Unit)
• GHC™ 50 Marine Autopilot Display
• ECU (Electronic Control Unit)
• ECU power cable
• Interconnect cable
• Buzzer
• NMEA 2000® drop cables (2 meters)
• NMEA 2000 T-connectors
• Male and female terminators
• Documentation

Sold individually.

Product Details

• Manufacturer: Garmin
• Part Number: 010-02794-02
• Product Type: Autopilots
• Condition: New

Important Fitment Information

Please verify that this product is compatible with your boat and your Garmin equipment before ordering. Always follow Garmin's installation instructions.

Final Sale: This item is final sale and not eligible for return. Please confirm compatibility before ordering. Questions? Call 954-946-1451.
